Cow Dung Manure Compost Chain Plate Compost Turner Fermentation Equipment
Chain plate compost turner fermentation equipment can efficiently shorten the fermentation period, improve the quality of products. Variable frequency speed control system can be well adapted to the change of working load. According to the material resistance, the speed of walking can be adjusted flexibly to make the equipment more adaptable and flexible.
The working system of chain plate composting machine adopts frequency conversion speed regulation, so it has the characteristics of good adaptability to different materials, smooth operation, high turnover efficiency and deep groove operation.
| Model |
TDLBF-4000 |
TDLBF-5000 |
| Turning Power(kw) |
22kw*2 |
22kw*2 |
| Moving Power(kw) |
3 |
2.2kw*2 |
| Turning Speed(m/h) |
30-90 |
30-90 |
| Lifting Power(kw) |
3 |
3 |
| Turning Width(mm) |
4000 |
5000 |
| Turning Depth(mm) |
1800 |
2000 |
| Turning Teeth Thickness(mm) |
8 |
10 |
Chain Plate Compost Turner Fermentation Equipment Performance Characteristics:
1.The bracket structure with chain drive and rolling support is adopted, which has small turning resistance and saves electricity and energy, and is suitable for deep groove operation.
2.Flexible tension and elastic shock absorber are equipped with flip-flop bracket to protect transmission system and working parts.
3.The turning pallet is equipped with a removable wear-resistant curved tooth 4.When flipping, the material stays on the tray for a long time, disperses at a high level, contacts with the air sufficiently, and is easy to precipitate.
5.Through horizontal and vertical displacement, it is possible to realize the turnover operation at any position in the tank.
6.The lifting and working parts are controlled by hydraulic system, flexible and safe.
7.Remote control of the machine’s advance, lateral movement, flip and quick astern can be done remotely to improve the operating environment.
8.Trough-type material distributor, automatic discharging device, solar fermentation chamber and ventilation and aeration system can be selected.
9.Equipped with transfer machine to change groove, it can realize multi slot operation of a turn over machine and save investment.
FAQ:
Q1: Are you trading company or manufacturer?
A: We are factory.
Q2: How long is your delivery time?
A: Generally it is 7-10 days if the goods are in stock. Or it is 15-30 days if the goods are not in stock, it is according to quantity.
Q3: What is your payment method?
A: 30% of total prices should be paid by T/T as down payment; 70% balance payment should b paid by T/T before delivery.
Q4: How long is the warrenty of your equipments? Does your company supply the spare parts?
A: The warranty period of fertilizer equipments is one year. And we will supply the spare parts for you at lowest cost.
Q5: If I need the complete fertilizer production line can you help us to build it?
A: Yes, we can help you set up a fertilizer production line and give you related professional advices as long as you need. We had already build many fertilizer production line projects in China & Oversea.
